• Specification

-   Wide application in measurement Small diameter thermocouple is very usefull for the place where space is at  premium. Mineral insulated construction is resistant to high pressure  and also used at    wide range of temperature from-200°C to +1260°C. -  Quick response Mineral  insulated thermocouples have small heat capacity due to the small  sheath size, the small thermal mass is highly sensitive to change in  temperature and  gives a very fast response. -   Easily bent for installation The ability to form mineral insulated thermocouples on a radius twice the  sheath diameter makes for simple and on-the-spot installation into  complex configurations. -   Long Iife span Contrary  to conventional thermocouples which suffer from deterioration of  electromotive force or wire disconnection, etc., mineral insulated  thermocouples wires are insulated with chemically stable magnesium oxide, thus assuring a longer service life. -   Excellent mechanical strength and pressure Resistance The composite construction is resistant to extreamely high vibration  levels, and by choosing appropriate sheath material, it is reliable to  use in corrosive atmospheres and   abnormally high or low temperatures.  Though it has small diameter, it can withstand about 350 MPa at a  temperature of 650°C. -   Custom sheath outer diameter available Sheath outer diameter sizes between 0.25mm and 12.7mm can be provided. -   Custom long length Length are available up to a maximum of 400m. Maximum length is dependent upon the sheath outer diameter.

• Specification

Measuring temperature range						Unit	℃
Sheath Diameter  (mm)	N	K			E	J	T
0.25	——	500			——	——	——
0.5	——	600			——	——	——
1.0	900	650		900	650	450	300
2.0	1200	650		1200	650	450	300
3.0	1260	750		1260	750	650	350
5.0		800		1260	800	750	350
6.0		1000	900	1260	800	750	350
8.0	——	1050	1000	——	800	750	350
Sheath material	Inconel 600/SUS310/H2300/SUS316
