• Measuring principle

  A fluid flowing with a certain velocity and passing a fixed obstruction generates vortices. The generation of vortices is known as Karman’s Vortices.The frequency of vortex shedding is a direct linear function of fluid velocity and frequency depends upon the shape and face width of bluff body. Since the width of obstruction and inner diameter of the pipe will be more or less constant, the frequency is given by the expression: f=(St*V)/c*D

• Installation

  Wafer connection: DN15-DN300(priority PN2.5MPa)

• Accuracy

1.5%, 1.0%

• Range Ratio

Gas density:1.2kg/m3, Range ratio: 8:1

• Medium Temperature

-20°C ~ +150°C、-20°C ~ +260°C、-20°C ~ +300°C

• Power Supply

24VDC±5% Li battery(3.6VDC)

• Output signal

4-20mA Frequency RS485 communication (Modbus RTU)

• Ingress protection

IP65

• Body Materials

  Stainless stell

• Display

  128*64 dot matrix LCD

  Noted: the product strictly prohibited to be used in explosion-proof occasions.
