• Advantages

• Dielectric strength (leakage current 1mA, with test time of 1 minute): ≥1500VAC (among input/output/power supply) • Insulation resistance: ≥100MΩ (among input/output/power supply) • EMC: EMC conforms to IEC61326-3 • Power supply: DC 18～32V (typical value 24V DC) • Full-load power: Single-channel input, single-channel output    0.6W Single-channel input, double-channel output   1.5W

• Specification

• Allowed input signal: DC: 0(4)mA～20mA；0mA～10mA Other signal types may be customized as required, see the product label for details; • Input impedance: about 100Ω • Allowed output signal: • Current: 0(4)mA～20mA；0mA～10mA Voltage: 0(1) V～5V；0V～10V Other signal types may be customized as required, see the product label for the specific signal types; • Output load capacity: 0(4)mA～20mA：≤550Ω；0mA~10mA：≤1.1kΩ 0(1)V～5V：≥1MΩ； 0V～10V：≥2MΩ Other load demands may be customized as required, see the product label for details. • Distribution output voltage: No-load voltage≤26V, full-load voltage≥23V Accuracy of isolated transmission: ±0.1%F∙S（25℃±2℃） • Temperature drift: 40ppm/℃ • Response time: ≤0.5s
